Product Selling points
Machine Details
Technical Parameters
| Category | Parameter | A | B | C | D |
|---|---|---|---|---|---|
Injection Unit | Screw Diameter | 90 | 100 | 110 | 120 |
| Screw L/D Ratio | 24.4 | 22 | 20 | 18.3 | |
| Shot Size (Theoretical) | 2799 | 3456 | 4181 | 4976 | |
| Injection Weight (PS) | 2547 | 3145 | 3805 | 4528 | |
| Injection Rate | 543 | 671 | 811 | 966 | |
| Injection Pressure | 228 | 184 | 152 | 128 | |
| Plasticizing Capacity (ps) | 73.0 | 90.2 | 109.1 | 129.8 | |
| Screw Speed | – | 0 – 110 | – | – | |
Clamping Unit | Clamp Tonnage | – | 7800 | – | – |
| Toggle Stroke | – | 980 | – | – | |
| Space Between Tie Bars | – | 980X980 | – | – | |
| Max.Mold Height | – | 980 | – | – | |
| Min. Mold Height | – | 400 | – | – | |
| Ejector Stroke | – | 260 | – | – | |
| Ejector Tonnage | – | 186 | – | – | |
Others | Max. Pump Pressure | – | 16 | – | – |
| Pump Motor Power | – | 22+55 | – | – | |
| Heater Power | – | 61.15 | – | – | |
| Machine Dimension (L×W×H) | – | 10.5×2.42×2.73 | – | – | |
| Machine Weight | – | 36 | – | – | |
| Hopper Capacity | – | 200 | – | – | |
| Oil Tank Capacity | – | 1425 | – | – |
